Sliding Bearing 0009234036 Linde — provides support and guidance for the shaft or moving elements, r..
57.60 $
excl. VAT 48.00 $
Hydraulics:
Pump & Motor Parts
Linde HPR135-02 — variable displacement axial piston hydraulic pump 135 cm³
Linde HPR135-02 is a variable displacement axial piston pump from the HPR-02 series for open hydraulic circuits. One of the largest sizes in the main series line (55–165 cm³). Cradle (cam rocker) design with a 21° inclination angle, integrated SPU pulsation damper, optimised inlet channel without tank pressurisation. The load sensing flow control system delivers precisely the volume demanded by the actuators at any given moment. Thru-shaft for mounting additional pumps. Used in Volvo and Atlas wheeled excavators.
Full model range in the section Linde HPR-02 series.
Technical specifications HPR135-02
- Max. displacement: 135 cm³
- Flow at 1500 rpm: 203 l/min
- Rated pressure: 420 bar
- Max. pressure (peak): 500 bar
Installed in equipment
-
Atlas
- 1604 — wheeled excavator
-
EcoLog
- 574B — forwarder
-
Volvo
- EW140B — wheeled excavator
- EW140C — wheeled excavator
- EW160B — wheeled excavator
- EW160C — wheeled excavator
- EW160D — wheeled excavator
OEM numbers HPR135-02
-
Linde
- HPR135-02R
- HPR135-02L
Spare part numbers HPR135-02
-
Linde
- 5803001058
- 5813001060
- 2553200802
- 2553230141
- 2553431804
- 2553431806
- 2553014005
- 2653200408
- 2653231414
- 2553450403
- 2853232005
- 2553240229
Spare parts for Linde HPR135-02
- Cylinder block Rotor
- Drive Shaft
- Separation Bush
- Ball guide
- Disk Spring
- Snap Ring
- Slider
- Coupling of drive shaft
- Cylinder block press pin
- Charge Pump
- Roller Bearing
- Cradle Bearing Set
- Retainer Plate
- Swash plate (cam rocker)
- Piston shoe
- Rotor Spring
- Seal kit pump
- Shaft Seal
- Wire
- Valve plate
- Ball guide washer
- Pressure Override Valve
- Control Valve Regulator
- Regulator assembly
- Servo Piston
Repair and service HPR135-02
We perform diagnostics and repair of pump Linde HPR135-02: checking hydraulic parameters, assessing the condition of the piston group and bench testing after restoration.
Contact us — we will repair pump HPR135-02 and select genuine spare parts.
Technical specifications verified by the Aspect Plus technical catalog.
