Description Piston shoe Sauer-danfoss PV90R75, PV90L75 SKS
Piston shoe Sauer-danfoss PV90R75 — performs reciprocating motion within the cylinder of the block, drawing in and displacing the working fluid, and through the ball-and-socket connection with the shoe provides continuous sliding contact with the swashplate surface as the cylinder block rotates. Used in John Deere, Timberjack. You can send a photo of the Sauer-Danfoss unit or machine nameplate in the chat, and we will help you select the required spare parts.
Compatible pumps / motors
-
Sauer-Danfoss
- PV90R75
Compatible equipment
-
Ammann
- ASC 110 — Soil Compactor
-
Bobcat
- T357 — Telehandler
-
Bomag
- BW120 AD — Soil Compactor
- BW138 AD — Soil Compactor
-
Case IH
- 1460 — Combine Harvester
- 1480 — Combine Harvester
-
Claas
- Dominator 76 — Combine Harvester
- Dominator 86 — Combine Harvester
- Dominator 96 — Combine Harvester
-
Dynapac
- CA252 — Soil Compactor
-
John Deere
- 4030 — Combine Harvester
- 6600 — Combine Harvester
- 6620 — Combine Harvester
- 7700 — Combine Harvester
- 7720 — Combine Harvester
- 4030 — Tractor
-
MAN
- TGS — Truck
-
New Holland
- TR70 — Combine Harvester
- TR75 — Combine Harvester
-
Timberjack
- 810 — Forwarder
- 1010 — Forwarder
Dimensions
- L = 78,5 mm
- D = 20,7 mm
- D1 = 10,0 mm
Main attributes Piston shoe Sauer-danfoss PV90R75, PV90L75 SKS
Plates, pistons, bushings for hydraulic systems
Plates, pistons, bushings for hydraulic systems
