Model: 10434
Spare part: Ball guide Sauer-danfoss 003160 HANDOK Part number: 003160 Cross-Number: 9210219 Use in:..
36.84 $
excl. VAT 30.70 $
Plates, pistons, bushings for hydraulic systems:
Plates, pistons, bushings for hydraulic systems
Most Viewed
Model: 12194
Spare part: Ball guide Sauer-Danfoss 003160 SKS Part number: 003160 Cross-Number: 9210219 Use in: Pl..
47.88 $
excl. VAT 39.90 $
Plates, pistons, bushings for hydraulic systems:
Plates, pistons, bushings for hydraulic systems
Most Viewed
Model: 10435
Spare part: Bearing Plate Sauer-danfoss 585885 HANDOK Part number: 585885 Cross-Number: Use in: Plea..
59.28 $
excl. VAT 49.40 $
Plates, pistons, bushings for hydraulic systems:
Plates, pistons, bushings for hydraulic systems
Most Viewed
Model: 12195
Spare part: Bearing Plate Sauer-Danfoss 585885 SKS Part number: 585885 Cross-Number: Use in: Please ..
75.12 $
excl. VAT 62.60 $
Plates, pistons, bushings for hydraulic systems:
Plates, pistons, bushings for hydraulic systems
Most Viewed
Model: 10939
Spare part: Bush Sauer-danfoss PV21 D=52.9 mm SKS Part number: Cross-Number: Use in: Sauer-danfoss P..
7.44 $
excl. VAT 6.20 $
Other parts:
Other parts
Most Viewed
Model: 11019
Spare part: Charge pump Sauer-danfoss PV20, PV21, PVD21, PV22, PV23, PVD23, PV24 SKS Part number: Cr..
240.48 $
excl. VAT 200.40 $
PTO, gear pumps, regulators:
PTO, gear pumps, regulators
Most Viewed
Model: 10941
Spare part: Connector Sauer-danfoss PV21 SKS Part number: Cross-Number: Use in: Sauer-danfoss PV21 U..
11.40 $
excl. VAT 9.50 $
Fasteners:
Fasteners
Most Viewed
Model: 10954
Spare part: Control Valve Regulator Sauer-danfoss PV20, PV21, PVD21, PV22 SKS Part number: Cross-Num..
213.72 $
excl. VAT 178.10 $
PTO, gear pumps, regulators:
PTO, gear pumps, regulators
Most Viewed
Model: 12197
Spare part: Cylinder block Rotor Sauer-Danfoss 049163 SKS Part number: 049163 Cross-Number: Use in: ..
233.52 $
excl. VAT 194.60 $
Main hydraulic units:
Main hydraulic units
Most Viewed
Model: 10444
Spare part: Cylinder block Rotor Sauer-danfoss PV21, SPV21, M21, MF21, PVD21 HANDOK Part number: Cro..
203.16 $
excl. VAT 169.30 $
Main hydraulic units:
Main hydraulic units
Most Viewed
Model: 12203
Spare part: Drive Shaft Motor Sauer-Danfoss 080465 SKS Part number: 080465 Cross-Number: Use in: Ple..
91.44 $
excl. VAT 76.20 $
Shafts of hydraulic pumps and motors:
Shafts of hydraulic pumps and motors
Most Viewed
Model: 12204
Spare part: Drive Shaft Sauer-Danfoss 9210673 SKS Part number: 9210673 Cross-Number: Use in: Please ..
66.84 $
excl. VAT 55.70 $
Shafts of hydraulic pumps and motors:
Shafts of hydraulic pumps and motors
Most Viewed
Model: 13224
Spare part: Drive Shaft Sauer-Danfoss PV21 L=282.0 mm, 21T/KEY SKS Part number: Cross-Number: Use in..
62.76 $
excl. VAT 52.30 $
Shafts of hydraulic pumps and motors:
Shafts of hydraulic pumps and motors
Most Viewed
Model: 13223
Spare part: Drive Shaft Sauer-Danfoss PV21 L=315.0 mm, 21T/13T SKS Part number: Cross-Number: Use in..
63.00 $
excl. VAT 52.50 $
Shafts of hydraulic pumps and motors:
Shafts of hydraulic pumps and motors
Most Viewed
Model: 14772
Spare part: Drive Shaft Sauer-Danfoss PV21, SPV21 SKS Part number: Cross-Number: Use in: Sauer-Danfo..
62.88 $
excl. VAT 52.40 $
Shafts of hydraulic pumps and motors:
Shafts of hydraulic pumps and motors
Characteristics of Sauer-Danfoss PV21 PVD21 SPV21 SPV2/052 SMF2/052 M/MF21 hydraulic motors
Sauer-Danfoss PV21, PVD21, SPV21, SPV2/052, SMF2/052, M/MF21 models are reliable, variable displacement axial piston units that can act as both a pump and a hydraulic motor. They are designed for use in open or closed loop hydrostatic transmissions, providing high efficiency and reliability in a variety of mobile and industrial applications.
Technical characteristics of Sauer-Danfoss hydraulic motors PV21 PVD21 SPV21 SPV2/052 SMF2/052 M/MF21:
- Construction type: swash plate
- Volume: from 52 to 520 cm3 (depending on model and configuration)
- Pressure: nominal — 210 bar, maximum — 350 bar
- Rotation speed: up to 2,500 rpm
- Weight: Varies depending on model and configuration
- Application: mobile machinery, construction machinery, agricultural machinery, mining machinery, transport mixers, municipal vehicles
Cross numbers of hydraulic motors:
Installed in the equipment model:
- Sauer-Danfoss PV21 / PVD21 (variable displacement axial piston pumps, ~21 cm3/rev): Wirtgen Group: Vögele Super 800, Super 1000, Hamm HD 10, HD 12 Caterpillar: mini excavators 302.7D, 303.5E, 304E, skid steer loaders 216B, 226B Volvo CE: EC27D, EC35D, EC55C, L25B JCB: 8018, 8026CTS, 8030ZTS, 55Z-1 Liebherr: R 904 Compact, L 506 Kubota: KX057, U55, U48 Bomag: BW 100, BW 120
- Sauer-Danfoss SPV21 (variable displacement axial piston pump, ~21 cm3/rev): Caterpillar: 303.5E, 304E, 305E Volvo CE: EC27D, EC35D, EC55C JCB: 8025ZTS, 8030ZTS, 55Z-1 Liebherr: R 904 Compact Kubota: U48, U55, KX057 Wirtgen Group: Hamm HD 10, HD 12
- Sauer-Danfoss SPV2/052 (variable displacement axial piston pump, ~52 cm3/rev): Caterpillar: 305E, 306CR, 307 Volvo CE: EC55C, EC60E, ECR58 JCB: 55Z-1, 57C-1, 85Z-1 Liebherr: R 914 Compact Kubota: U55, KX080
- Sauer-Danfoss SMF2/052 (constant displacement hydraulic motor, ~52 cm3/rev): Wirtgen Group: Vögele Super 1300-3i, Super 1600-3i, Hamm DV+ 70i Caterpillar: 305E, 306CR Volvo CE: EC55C, EC60E JCB: 57C-1, 85Z-1 Kubota: KX080
- Sauer-Danfoss M/MF21 (constant displacement hydraulic motor, ~21 cm3/rev): Wirtgen Group: Vögele Super 800, Super 1000, Hamm HD 8, HD 10 Caterpillar: 302.7D, 303.5E Volvo CE: EC27D, EC35D JCB: 8026CTS, 8030ZTS Kubota: U48, U55 Holder, Aebi Schmidt: compact municipal vehicles, snow throwers
The company "Aspect Plus" offers a wide range of spare parts for the repair of the Sauer-Danfoss PV21 PVD21 SPV21 SPV2/052 SMF2/052 M/MF21 hydraulic motor.
