HMGF57A HMV155

Characteristics of the Hitachi HMGF57A (HMV155) motor

The HMGF57A (HMV155) hydraulic motor is an axial piston hydraulic motor with an inclined block and variable displacement, designed for use in heavy mobile and industrial equipment. Due to its power and durability, this motor is ideal for operation under high loads and variable conditions.

Technical specifications Hitachi HMGF57A (HMV155):

• Type: axial piston motor with variable displacement.
• Maximum working volume: 155 cm³ per revolution
• Working pressure
  • Nominal pressure: 31.5 MPa 315 bar
  • Maximum pressure: 35 MPa 350 bar
• Rotation speed:
  • Maximum: up to 1800 rpm
• Weight: 100–120 kg (depending on configuration)
• Application in special equipment: excavators, loaders, drilling rigs, machines for transporting and processing minerals, crushers, conveyor systems, hydraulic drives for heavy equipment, crawler systems, heavy machinery

Analogues of the Hitachi hydraulic motor catalog number Hitachi HMGF57A (HMV155): 9155694, 9149125, 9205359, 9205360, 9190296, 9195488, 1019564, 2040523, 4199108, 4199072, 4191665, 4389598, 4191666, 4038529, 2040520, 8068583, 3078298, 4194362, 4198956, 3036457, 3036456, 4193996, 3078190, 4252401, 4269474, 3054505, 4269473, 4506415, 9157762, 9158391, M341850, 2035236, 4364104, 2040522, 4234628, 4255238, 2040803, 4262561, 9157588, 4260308, 4265579, 9134112, 4506418, 9134109, 4506408, 4438768, M341225

Installed in the model: ZX330, ZX330-HHE, ZX350H, ZX350H, ZX350K, ZX350K, ZX350LC-AMS, ZX350LC-AMS, ZX350LC-HCME, ZX350LC-HCME, ZX360LC-HHE, ZX370MTH, ZX370MTH, EX270-5, EX280H-5, EX300-5, EX300-5HHE, EX300LC-5M, EX300LCLL-5, EX300LCLL-5M, EX345USR(LC), EX350H-5, EX350H-5HHE, EX350K-5, EX370-5M, EX370HD-5, EX370LL-5M, EX385USR

The company "Aspect Plus" offers a wide range of spare parts for repairing the Hitachi HMGF57A (HMV155) hydraulic motor.
