K3VL80

Kawasaki K3VL80 hydraulic pump specifications

The Kawasaki K3VL80 hydraulic pump is a variable displacement axial piston pump with a swash plate designed for open hydraulic systems in mobile and industrial applications.

Technical specifications of the Kawasaki K3VL80 hydraulic pump:

• Type: Swash plate axial piston pump
• Displacement: 80 cm³/rev
• Nominal pressure: 320 bar
• Maximum pressure: 350 bar
• Maximum rotation speed: 2400 rpm
• Weight: approximately 35 kg
• Direction of rotation: right (clockwise)
• Mounting type: SAE flange with splined shaft
• Working fluid: Mineral hydraulic oil with anti-wear properties
• Viscosity range: 200–1000 cSt
• Applications: excavators, loaders, cranes, tractors, combines, injection machines, fans, garbage trucks

Design features of the Kawasaki K3VL80 hydraulic pump:

• Configurations: single-section
• Types of regulators: mechanical, hydraulic, electro-hydraulic, load-compensated (LS), pressure and combined
• Additional options: presence or absence of PTO (power take-off shaft)

The Kawasaki K3VL80 hydraulic pump has the following advantages::

• High reliability: durability and wear resistance
• Compact: easy to install in limited space
• Flexibility: adaptability to different operating conditions thanks to a wide choice of configurations and regulators
• High performance: stable oil supply even under high loads

Hydraulic pump cross number:

Installed in the model:

The company "Aspect Plus" offers a wide range of spare parts for repairing the Kawasaki K3VL80 hydraulic pump.
